ACE SA 210 W Piling Rig
Action Construction Equipment Limited
Haryana
The ACE SA 210 W Piling Rig is a high-performance, rugged machine designed for tough soil conditions, making it ideal for a variety of demanding construction projects. With its powerful Cummins engine and impressive rotary power head offering a maximum torque of 205 kN.m, this rig is perfect for urban infrastructure, metro systems, and rapid rail connectivity. It efficiently handles deep drilling requirements, with depths up to 62 meters using a friction kelly bar, and can drill piles up to 1600 mm in diameter. The ACE SA 210 W is also versatile enough for use in bridge construction, flyovers, and tunnel boring operations. Its advanced winch systems, high lifting force, and adjustable drill mast make it an excellent solution for large-scale general construction and underground foundation work.
ACE SA 210 W Piling Rig
Action Construction Equipment Limited
Haryana
The ACE SA 210 W Piling Rig is a high-performance, rugged machine designed for tough soil conditions, making it ideal for a variety of demanding construction projects. With its powerful Cummins engine and impressive rotary power head offering a maximum torque of 205 kN.m, this rig is perfect for urban infrastructure, metro systems, and rapid rail connectivity. It efficiently handles deep drilling requirements, with depths up to 62 meters using a friction kelly bar, and can drill piles up to 1600 mm in diameter. The ACE SA 210 W is also versatile enough for use in bridge construction, flyovers, and tunnel boring operations. Its advanced winch systems, high lifting force, and adjustable drill mast make it an excellent solution for large-scale general construction and underground foundation work.
Product Description
The ACE SA 210 W Piling Rig is a high-performance, rugged machine designed for tough soil conditions...
View the full brochure
ACE SA 210 W Piling Rig Comparison with Similar Piling Rig
ACE SA 210 W Piling Rig
Wire Rope Diameter
-
Max. Lifting Capacity
200kN
Max. Line Speed
75m/min
Swing Radius
-
Overall Height
20400mm
Transport Height
-
Transport Width
-
Operating Weight
66.3Ton
Max. Traction Force
-
Max. Travel Speed
1.63km/h
Max. Gradeability
15°
Friction Kelly Bar
62000mm
Interlocking Kelly Bar
50000mm
Engine Brand
Cummins
Engine Model
-
Engine Power
194kW
Rated Speed
2200rpm
Emission Standard
-
Engine Displacement
-
Max Output Torque
205kN·m
Rotation Speed Range
26rpm
High Speed Throwing Soil
70rpm
Max. Drilling Diameter
1600mm
Max. Drilling Depth (interlocking Kelly)
50m
Max. Drilling Depth (friction Kelly)
62m
Crowd Force (push)
230kN
Crowd Force (pull)
230kN
Stroke Length
13700mm
Forward Tilt
5°
Backward Tilt
-
Lateral Tilt
-
Track Shoe Width
700mm
Chassis Length
5145mm
Crawler Extension Width
4200mm
