CASE 1107 EX Soil Compactor
Gulati Cranes
Maharashtra
The CASE 1107 EX Tandem Roller is a high-performance vibratory soil compactor designed for a variety of construction and infrastructure applications. Powered by a robust AL H4 engine, this machine offers exceptional efficiency and reliability. With a weight of 10,800 kg and a frequency of 31 Hz, it ensures optimal compaction results for a wide range of materials. The 1107 EX features advanced safety systems, including an audio-visual warning, engine protection shutdown, and a secondary brake switch, enhancing operator safety. Its proven 4-point articulation joint and foldable canopy provide unmatched maneuverability and ease of transportation. The roller’s two vibration stages, shorter turning radius, and superior versatility make it ideal for compacting soil in tight spaces, road construction, landscaping, and more, making it an essential tool for professionals in construction and infrastructure projects.
CASE 1107 EX Soil Compactor
Gulati Cranes
Maharashtra
The CASE 1107 EX Tandem Roller is a high-performance vibratory soil compactor designed for a variety of construction and infrastructure applications. Powered by a robust AL H4 engine, this machine offers exceptional efficiency and reliability. With a weight of 10,800 kg and a frequency of 31 Hz, it ensures optimal compaction results for a wide range of materials. The 1107 EX features advanced safety systems, including an audio-visual warning, engine protection shutdown, and a secondary brake switch, enhancing operator safety. Its proven 4-point articulation joint and foldable canopy provide unmatched maneuverability and ease of transportation. The roller’s two vibration stages, shorter turning radius, and superior versatility make it ideal for compacting soil in tight spaces, road construction, landscaping, and more, making it an essential tool for professionals in construction and infrastructure projects.
Product Description
The CASE 1107 EX Tandem Roller is a high-performance vibratory soil compactor designed for a variety...
View the full brochure
CASE 1107 EX Soil Compactor Comparison with Similar Single Drum Soil Compactor
CASE 1107 EX Soil Compactor
Ground Clearance
362mm
Drum Width
2.15m
Fuel Tank Capacity
-
Displacement
3.83L
Transmission Type
-
Max Travel Speed
-
Max Working Speed
-
Gradeability Without Vibration
-
Gradeability With Vibration
-
Water Tank Capacity
-
Parking Brake Type
-
Service Brake Type
-
Engine Brand
AL
Engine Model
H4
Engine Power
100HP
Max Torque
450Nm
Rated Speed
2200rpm
Steering Type
Articulated Hydrostatic Steering
Steering Angle
37°
Oscillation Angle
15°
Turning Radius
5.83m
Operating Weight
10.8Ton
Front Axle Load
5800kg
Rear Axle Load
5000kg
Hydraulic Tank Capacity
70L
Frequency High
31Hz
Frequency Low
31Hz
Amplitude High
2.0mm
Amplitude Low
0.6mm
Overall Length
5.51m
Overall Width
2.32m
Overall Height
3.37 m
Turning Radius (inner)
-
Turning Radius (outer)
-
Static Linear Load
-
Frequency (low)
-
Frequency (high)
-
Amplitude (low)
-
Amplitude (high)
-
Centrifugal Force
-
Max Applied Force
-
Without Drum Drive
-
With Drum Drive
-
Drum Diameter
-
Drum Shell Thickness
-
Rear Departure Angle
-
Front Departure Angle
-
Hydraulic Oil Capacity
-
Engine Oil Capacity
-
Coolant Capacity
-
Tyre Size
-
Battery Voltage
-
Battery Capacity
-
LiuGong 611 Soil Compactor
Ground Clearance
460 mm
Drum Width
2.13 m
Fuel Tank Capacity
280 L
Displacement
4.76 L
Transmission Type
Hydrostatic
Max Travel Speed
13 km/h
Max Working Speed
-
Gradeability Without Vibration
-
Gradeability With Vibration
-
Water Tank Capacity
-
Parking Brake Type
Spring Applied, Hydraulic Release
Service Brake Type
Hydrostatic Propulsion System
Engine Brand
Kirloskar
Engine Model
4R1190TA1
Engine Power
110 HP
Max Torque
450 Nm
Rated Speed
2200 rpm
Steering Type
Articulation
Steering Angle
70 (±35°) °
Oscillation Angle
-
Turning Radius
-
Operating Weight
11.0 Ton
Front Axle Load
-
Rear Axle Load
-
Hydraulic Tank Capacity
-
Frequency High
-
Frequency Low
-
Amplitude High
-
Amplitude Low
-
Overall Length
5.9 m
Overall Width
2.3 m
Overall Height
3.232 m
Turning Radius (inner)
-
Turning Radius (outer)
<6.75 m
Static Linear Load
-
Frequency (low)
32Hz
Frequency (high)
34 Hz
Amplitude (low)
0.8 mm
Amplitude (high)
1.8 mm
Centrifugal Force
125 kN
Max Applied Force
385.32 kN
Without Drum Drive
-
With Drum Drive
35 %
Drum Diameter
1.5 m
Drum Shell Thickness
-
Rear Departure Angle
-
Front Departure Angle
-
Hydraulic Oil Capacity
90 L
Engine Oil Capacity
8.5 L
Coolant Capacity
18 L
Tyre Size
23.1-26-12PR
Battery Voltage
12 V
Battery Capacity
150 Ah
Dynapac CA405D CEV-V Single drum vibratory rollers
Ground Clearance
520mm
Drum Width
2.130m
Fuel Tank Capacity
280L
Displacement
-
Transmission Type
Hydrostatic
Max Travel Speed
10.8km/h
Max Working Speed
-
Gradeability Without Vibration
-
Gradeability With Vibration
-
Water Tank Capacity
-
Parking Brake Type
Failsafe multidisc brake in rear axle and front drum motor
Service Brake Type
Hydrostatic in forward and reverse lever
Engine Brand
Cummins
Engine Model
-
Engine Power
121HP
Max Torque
-
Rated Speed
2200rpm
Steering Type
Hydrostatic
Steering Angle
38°
Oscillation Angle
9°
Turning Radius
-
Operating Weight
13.960Ton
Front Axle Load
8580kg
Rear Axle Load
5260kg
Hydraulic Tank Capacity
-
Frequency High
-
Frequency Low
-
Amplitude High
-
Amplitude Low
-
Overall Length
5.600m
Overall Width
2.300m
Overall Height
2.977m
Turning Radius (inner)
3.385m
Turning Radius (outer)
5.515m
Static Linear Load
40.3kg/cm
Frequency (low)
33Hz
Frequency (high)
33Hz
Amplitude (low)
0.8mm
Amplitude (high)
1.7mm
Centrifugal Force
300kN
Max Applied Force
-
Without Drum Drive
50%
With Drum Drive
-
Drum Diameter
1.543m
Drum Shell Thickness
0.035m
Rear Departure Angle
-
Front Departure Angle
-
Hydraulic Oil Capacity
-
Engine Oil Capacity
-
Coolant Capacity
-
Tyre Size
23.1-26 TL
Battery Voltage
-
Battery Capacity
-
Ammann ARS 30 PD Single Drum Roller
Ground Clearance
-
Drum Width
1.2m
Fuel Tank Capacity
98L
Displacement
-
Transmission Type
-
Max Travel Speed
9.5km/h
Max Working Speed
-
Gradeability Without Vibration
-
Gradeability With Vibration
-
Water Tank Capacity
-
Parking Brake Type
Multi Disc
Service Brake Type
-
Engine Brand
Kubota
Engine Model
V2403-CR-T
Engine Power
-
Max Torque
-
Rated Speed
-
Steering Type
-
Steering Angle
30°
Oscillation Angle
10°
Turning Radius
-
Operating Weight
3.49Ton
Front Axle Load
-
Rear Axle Load
-
Hydraulic Tank Capacity
-
Frequency High
-
Frequency Low
-
Amplitude High
-
Amplitude Low
-
Overall Length
-
Overall Width
-
Overall Height
-
Turning Radius (inner)
2.8m
Turning Radius (outer)
-
Static Linear Load
-
Frequency (low)
29Hz
Frequency (high)
38Hz
Amplitude (low)
1.5mm
Amplitude (high)
-
Centrifugal Force
68kN
Max Applied Force
-
Without Drum Drive
-
With Drum Drive
-
Drum Diameter
-
Drum Shell Thickness
-
Rear Departure Angle
-
Front Departure Angle
-
Hydraulic Oil Capacity
-
Engine Oil Capacity
-
Coolant Capacity
-
Tyre Size
-
Battery Voltage
-
Battery Capacity
-
Ammann ARS 110.2 Single Drum Roller
Ground Clearance
-
Drum Width
2.13m
Fuel Tank Capacity
310L
Displacement
-
Transmission Type
Hydrostatic
Max Travel Speed
11.5km/h
Max Working Speed
-
Gradeability Without Vibration
-
Gradeability With Vibration
-
Water Tank Capacity
-
Parking Brake Type
Multi Disc
Service Brake Type
Hydrostatic
Engine Brand
Ashok Leyland
Engine Model
H4C410122
Engine Power
99.2HP
Max Torque
-
Rated Speed
1400rpm
Steering Type
-
Steering Angle
36°
Oscillation Angle
10°
Turning Radius
-
Operating Weight
11.1Ton
Front Axle Load
-
Rear Axle Load
-
Hydraulic Tank Capacity
-
Frequency High
-
Frequency Low
-
Amplitude High
-
Amplitude Low
-
Overall Length
-
Overall Width
-
Overall Height
-
Turning Radius (inner)
3.25m
Turning Radius (outer)
-
Static Linear Load
29.1kg/cm
Frequency (low)
32Hz
Frequency (high)
35Hz
Amplitude (low)
0.9mm
Amplitude (high)
1.85mm
Centrifugal Force
275kN
Max Applied Force
275kN
Without Drum Drive
35%
With Drum Drive
-
Drum Diameter
-
Drum Shell Thickness
-
Rear Departure Angle
-
Front Departure Angle
-
Hydraulic Oil Capacity
-
Engine Oil Capacity
-
Coolant Capacity
-
Tyre Size
-
Battery Voltage
-
Battery Capacity
-
