CAT 2021E Wheel Loader
The CAT 2021E Wheel Loader is a high-performance machine built to deliver exceptional productivity, fuel efficiency, and operator comfort in every application. Its advanced Z-bar loader linkage combines the fast loading performance of a traditional Z-bar with the precise parallel lift of a tool carrier—making it ideal for construction, quarrying, agriculture, and material handling. The 2021E offers increased lift height, allowing for faster and easier truck loading while maintaining excellent stability and control. With high fill factors and lower fuel consumption per ton moved, this loader ensures maximum output with minimal operational cost. Designed for long shifts, it features a comfortable cab and extended service intervals, reducing downtime and increasing uptime. Whether on rugged job sites or bulk handling yards, the CAT 2021E is built to perform reliably.
CAT 2021E Wheel Loader
The CAT 2021E Wheel Loader is a high-performance machine built to deliver exceptional productivity, fuel efficiency, and operator comfort in every application. Its advanced Z-bar loader linkage combines the fast loading performance of a traditional Z-bar with the precise parallel lift of a tool carrier—making it ideal for construction, quarrying, agriculture, and material handling. The 2021E offers increased lift height, allowing for faster and easier truck loading while maintaining excellent stability and control. With high fill factors and lower fuel consumption per ton moved, this loader ensures maximum output with minimal operational cost. Designed for long shifts, it features a comfortable cab and extended service intervals, reducing downtime and increasing uptime. Whether on rugged job sites or bulk handling yards, the CAT 2021E is built to perform reliably.
Product Description
The CAT 2021E Wheel Loader is a high-performance machine built to deliver exceptional productivity, ...
CAT 2021E Wheel Loader Comparison with Similar Wheel Loader

CAT 2021E Wheel Loader
Engine Brand
Ashok Leyland
Engine Model
H6C413323
Engine Power
98kW
Max Torque
475Nm
Rated Speed
2300rpm
Displacement
5.76L
Fuel Tank Capacity
181L
Hydraulic Oil Capacity
127L
Transmission Type
Powershift with twin turbine torque converter
Number Of Gears (f/r)
2 / 1
Max Travel Speed (f)
25.8km/h
Max Travel Speed (r)
9.5km/h
Service Brake Type
Air actuated, dual circuit
Parking Brake Type
Mechanical shoe brake
Steering Type
Load sensing with priority valve
Steering Angle
40°
Oscillation Angle
11°
Turning Radius
5.598m
Operating Weight
11637kg
Front Axle Load
-
Rear Axle Load
-
Max Lifting Capacity
3210kg
Hydraulic Flow Rate
196L/min
Hydraulic Pressure
155Bar
Overall Length
7.034m
Overall Width
2.362m
Overall Height
4.893m
Ground Clearance
367mm
Max Dump Height
2.936m
Max Load Over Height
3.453m
Max Reach At Full Height
1.157m
Loader Bucket Capacity
1.53 – 3.0m³
Loader Arm Breakout Force
-
Front Axle Oscillation
11°
Battery Voltage
-
Standard Tires (front/rear)
14.00 x 25 - 20PR E3/L3

Volvo L350H Wheel Loader
Engine Brand
Volvo
Engine Model
D16E
Engine Power
397kW
Max Torque
2550Nm
Rated Speed
1700–1800rpm
Displacement
16.1L
Fuel Tank Capacity
540L
Hydraulic Oil Capacity
365L
Transmission Type
Volvo HTL 500, APS, ECM controlled
Number Of Gears (f/r)
4/4
Max Travel Speed (f)
37.7km/h
Max Travel Speed (r)
37.7km/h
Service Brake Type
Dual circuit, oil-cooled, wet disc brakes
Parking Brake Type
Dry, spring-applied, electro-hydraulically released
Steering Type
Load-sensing hydrostatic articulated steering
Steering Angle
±37°
Oscillation Angle
±12°
Turning Radius
-
Operating Weight
-
Front Axle Load
-
Rear Axle Load
-
Max Lifting Capacity
-
Hydraulic Flow Rate
827L/min
Hydraulic Pressure
29Bar
Overall Length
-
Overall Width
-
Overall Height
-
Ground Clearance
550mm
Max Dump Height
-
Max Load Over Height
-
Max Reach At Full Height
-
Loader Bucket Capacity
-
Loader Arm Breakout Force
-
Front Axle Oscillation
±12°
Battery Voltage
24V
Standard Tires (front/rear)
35/65 R33 L4

Volvo L260H Wheel Loader
Engine Brand
Volvo
Engine Model
D13E
Engine Power
310kW
Max Torque
2343Nm
Rated Speed
1400–1900rpm
Displacement
12.8L
Fuel Tank Capacity
366L
Hydraulic Oil Capacity
226L
Transmission Type
Volvo Automatic Power Shift (APS), 4-speed
Number Of Gears (f/r)
4/4
Max Travel Speed (f)
36.5km/h
Max Travel Speed (r)
36.1km/h
Service Brake Type
Wet disc, oil-cooled, outboard-mounted
Parking Brake Type
Dry disc, electro-hydraulic
Steering Type
Load-sensing hydrostatic articulated
Steering Angle
37°
Oscillation Angle
15°
Turning Radius
-
Operating Weight
33.76kg
Front Axle Load
-
Rear Axle Load
-
Max Lifting Capacity
-
Hydraulic Flow Rate
252L/min
Hydraulic Pressure
290Bar
Overall Length
9.31m
Overall Width
3.58m
Overall Height
6.46m
Ground Clearance
600mm
Max Dump Height
3.33m
Max Load Over Height
6.46m
Max Reach At Full Height
2.28m
Loader Bucket Capacity
6.1m³
Loader Arm Breakout Force
311kN
Front Axle Oscillation
15°
Battery Voltage
24V
Standard Tires (front/rear)
29.5 R25 L4

Volvo L150H Wheel Loader
Engine Brand
Volvo
Engine Model
D13F
Engine Power
300kW
Max Torque
1999Nm
Rated Speed
1300rpm
Displacement
12.8L
Fuel Tank Capacity
366L
Hydraulic Oil Capacity
156L
Transmission Type
Volvo HTL 223
Number Of Gears (f/r)
-
Max Travel Speed (f)
38km/h
Max Travel Speed (r)
-
Service Brake Type
Wet Disc
Parking Brake Type
Dry Disc
Steering Type
Articulated
Steering Angle
37°
Oscillation Angle
15°
Turning Radius
-
Operating Weight
26.47kg
Front Axle Load
-
Rear Axle Load
-
Max Lifting Capacity
7700kg
Hydraulic Flow Rate
180L/min
Hydraulic Pressure
290Bar
Overall Length
8.58m
Overall Width
2.93m
Overall Height
3.51m
Ground Clearance
0.61mm
Max Dump Height
3.15m
Max Load Over Height
-
Max Reach At Full Height
-
Loader Bucket Capacity
4.0m³
Loader Arm Breakout Force
201.2kN
Front Axle Oscillation
15°
Battery Voltage
24V
Standard Tires (front/rear)
26.5 R25 L3

Volvo L120H Wheel Loader
Engine Brand
Volvo
Engine Model
D8L
Engine Power
190kW
Max Torque
1125Nm
Rated Speed
1700 - 2240rpm
Displacement
7.8L
Fuel Tank Capacity
270L
Hydraulic Oil Capacity
140L
Transmission Type
Volvo HTE 206F APS
Number Of Gears (f/r)
4/4
Max Travel Speed (f)
40km/h
Max Travel Speed (r)
40km/h
Service Brake Type
Wet disc, dual circuit with accumulators
Parking Brake Type
Wet multi-disc, spring applied, electro-hydraulic release
Steering Type
Hydrostatic articulated, load-sensing
Steering Angle
40°
Oscillation Angle
13°
Turning Radius
-
Operating Weight
20.21kg
Front Axle Load
-
Rear Axle Load
-
Max Lifting Capacity
-
Hydraulic Flow Rate
128L/min
Hydraulic Pressure
290Bar
Overall Length
8.93m
Overall Width
2.99m
Overall Height
3.33m
Ground Clearance
435mm
Max Dump Height
2.84m
Max Load Over Height
4.66m
Max Reach At Full Height
-
Loader Bucket Capacity
3.8m³
Loader Arm Breakout Force
163.7kN
Front Axle Oscillation
13°
Battery Voltage
24V
Standard Tires (front/rear)
23.5 R25 L3
