JCB 37C Mini Excavator
JCB India Limited
Chhattisgarh
The JCB 37C HD Mini Excavator is a versatile, powerful machine built to meet the demands of modern construction in confined spaces. With a conventional tail swing design, this excavator offers superior maneuverability, making it ideal for urban projects and tight job sites. Equipped with a heavy-duty boom and arm made from high tensile steel, it ensures reliability and durability in the toughest conditions. The 37C HD delivers exceptional performance with a maximum dig depth of 3.48 meters and a bucket capacity of 0.11 cu.m. Comfort features like a suspension seat, USB port, and easy-access maintenance design add to its efficiency. Proudly made in India, this mini excavator sets new standards in productivity and safety, backed by JCB's trusted network across the country.
JCB 37C Mini Excavator
JCB India Limited
Chhattisgarh
The JCB 37C HD Mini Excavator is a versatile, powerful machine built to meet the demands of modern construction in confined spaces. With a conventional tail swing design, this excavator offers superior maneuverability, making it ideal for urban projects and tight job sites. Equipped with a heavy-duty boom and arm made from high tensile steel, it ensures reliability and durability in the toughest conditions. The 37C HD delivers exceptional performance with a maximum dig depth of 3.48 meters and a bucket capacity of 0.11 cu.m. Comfort features like a suspension seat, USB port, and easy-access maintenance design add to its efficiency. Proudly made in India, this mini excavator sets new standards in productivity and safety, backed by JCB's trusted network across the country.
Product Description
The JCB 37C HD Mini Excavator is a versatile, powerful machine built to meet the demands of modern c...
View the full brochure
JCB 37C Mini Excavator Comparison with Similar Mini Excavators

JCB 37C Mini Excavator
Engine Brand
JCB
Engine Model
Perkins 403J-17
Engine Power
25.3HP
Max Torque
91.9Nm
Rated Speed
-
Displacement
1.662L
Fuel Tank Capacity
50L
Hydraulic Flow Rate
-
Hydraulic Pressure (implement Circuit)
255kgf/cm²
Hydraulic Pressure (swing Circuit)
220kgf/cm²
Hydraulic Pressure (travel Circuit)
-
Hydraulic Pressure (pilot Circuit)
-
Operating Weight
4.05Ton
Max Digging Depth
3.34m
Max Reach At Ground
5.02m
Max Digging Height
4.73m
Max Dumping Height
3.54m
Bucket Capacity
-
Bucket Breakout Force
3304kgf
Arm Crowd Force
2009kgf
Overall Length
4.81m
Overall Height
2.48m
Ground Clearance
275mm

Sany SY20U Mini Excavator
Engine Brand
YANMAR
Engine Model
3TNV80F
Engine Power
19.8HP
Max Torque
67.4Nm
Rated Speed
2400rpm
Displacement
1.22L
Fuel Tank Capacity
21L
Hydraulic Flow Rate
70L/min
Hydraulic Pressure (implement Circuit)
250kgf/cm²
Hydraulic Pressure (swing Circuit)
166kgf/cm²
Hydraulic Pressure (travel Circuit)
250kgf/cm²
Hydraulic Pressure (pilot Circuit)
41kgf/cm²
Operating Weight
1.95Ton
Max Digging Depth
2.38m
Max Reach At Ground
4.01m
Max Digging Height
3.41m
Max Dumping Height
2.35m
Bucket Capacity
0.05m³
Bucket Breakout Force
1692.72kgf
Arm Crowd Force
938.13kgf
Overall Length
3.515m
Overall Height
2.49m
Ground Clearance
160mm

Empower Mini Excavator
Engine Brand
-
Engine Model
-
Engine Power
-
Max Torque
-
Rated Speed
-
Displacement
-
Fuel Tank Capacity
-
Hydraulic Flow Rate
-
Hydraulic Pressure (implement Circuit)
-
Hydraulic Pressure (swing Circuit)
-
Hydraulic Pressure (travel Circuit)
-
Hydraulic Pressure (pilot Circuit)
-
Operating Weight
-
Max Digging Depth
-
Max Reach At Ground
-
Max Digging Height
-
Max Dumping Height
-
Bucket Capacity
-
Bucket Breakout Force
-
Arm Crowd Force
-
Overall Length
-
Overall Height
-
Ground Clearance
-

Sany SY60C Mini Excavator
Engine Brand
Isuzu
Engine Model
4JG1
Engine Power
48.9HP
Max Torque
175Nm
Rated Speed
2100rpm
Displacement
3.05L
Fuel Tank Capacity
130L
Hydraulic Flow Rate
138L/min
Hydraulic Pressure (implement Circuit)
253.0kgf/cm²
Hydraulic Pressure (swing Circuit)
194.76kgf/cm²
Hydraulic Pressure (travel Circuit)
252.88kgf/cm²
Hydraulic Pressure (pilot Circuit)
35.7kgf/cm²
Operating Weight
-
Max Digging Depth
3.815 m
Max Reach At Ground
6.090 m
Max Digging Height
5.690 m
Max Dumping Height
3.930 m
Bucket Capacity
0.26m³
Bucket Breakout Force
4590 kgf
Arm Crowd Force
3360kgf
Overall Length
5.925m
Overall Height
2.595m
Ground Clearance
330mm

Tata Hitachi EX 210LC Prime Mini Excavator
Engine Brand
Cummins
Engine Model
6BT5.9C
Engine Power
131HP
Max Torque
54.8Nm
Rated Speed
2000rpm
Displacement
-
Fuel Tank Capacity
300L
Hydraulic Flow Rate
2 × 221L/min
Hydraulic Pressure (implement Circuit)
285kgf/cm²
Hydraulic Pressure (swing Circuit)
275kgf/cm²
Hydraulic Pressure (travel Circuit)
350kgf/cm²
Hydraulic Pressure (pilot Circuit)
40kgf/cm²
Operating Weight
20.6Ton
Max Digging Depth
5.87m
Max Reach At Ground
9.25m
Max Digging Height
9.4m
Max Dumping Height
6.6m
Bucket Capacity
0.91 - 1.7m³
Bucket Breakout Force
12,250kgf
Arm Crowd Force
9,700 - 11,700kgf
Overall Length
9.579m
Overall Height
3.112m
Ground Clearance
440mm
