Macons MST-4 Self Loading Transit Mixer
Macons Equipments
Gujarat
The Macons MST-4 Self Loading Transit Mixer is a versatile and efficient machine designed for on-site concrete mixing and transportation. It features user-friendly operation and a durable design that minimizes wear and tear, resulting in better productivity and higher cost-effectiveness. The mixer is equipped with a 4-wheel drive and 4-wheel steering system, allowing for enhanced maneuverability and easy operation in tight spaces and on challenging terrains with a 35% gradeability. Its 180° reversible driving post provides added flexibility in movement. The electronic weigh batching unit ensures precise and consistent concrete mixing, essential for quality construction. With reliable after-sales service available around the clock, the MST-4 is perfect for small to medium-sized projects, offering high efficiency and flexibility in commercial, residential, and infrastructure applications.
Macons MST-4 Self Loading Transit Mixer
Macons Equipments
Gujarat
The Macons MST-4 Self Loading Transit Mixer is a versatile and efficient machine designed for on-site concrete mixing and transportation. It features user-friendly operation and a durable design that minimizes wear and tear, resulting in better productivity and higher cost-effectiveness. The mixer is equipped with a 4-wheel drive and 4-wheel steering system, allowing for enhanced maneuverability and easy operation in tight spaces and on challenging terrains with a 35% gradeability. Its 180° reversible driving post provides added flexibility in movement. The electronic weigh batching unit ensures precise and consistent concrete mixing, essential for quality construction. With reliable after-sales service available around the clock, the MST-4 is perfect for small to medium-sized projects, offering high efficiency and flexibility in commercial, residential, and infrastructure applications.
Product Description
The Macons MST-4 Self Loading Transit Mixer is a versatile and efficient machine designed for on-sit...
View the full brochure
Macons MST-4 Self Loading Transit Mixer Comparison with Similar Self Loading Concrete Mixer
Macons MST-4 Self Loading Transit Mixer
Engine Brand
Kirloskar -
Engine Model
-
Engine Power
110HP
Rated Speed
2200RPM
Cooling System
-
Emission Compliance
-
Fuel Tank Capacity
130L
Max Travel Speed
24km/h
Working Speed
-
Gradeability
35° / %
Drive Type
4 Wheel Drive
Service Brake Type
Oil-bath disc brakes
Parking Brake Type
Electrical
Steering Type
Power Assisted
Steering Modes
-
Turning Radius
-
Drum Output Per Batch
4Cu.M
Drum Volume
5.3L
Drum Rotation
22RPM
Concrete Output Efficiency
-
Loader Bucket Capacity
800L
Loading Shovel System
-
Hydraulic Oil Capacity
-
Hydraulic Flow Rate
-
Hydraulic Pressure
-
Wheelbase
-
Operating Weight
7.98kg
Laden Weight
17.58kg
Tyre Size
405/70-20 16 PR
Tyre Type
-
Water Tank Capacity
900L
Water Pump Capacity
230L/min
Water System Features
-
Battery Voltage
12V
Battery Capacity
-
Additional Features
Rotating seat, Protection cabin
Schwing SLM 2100 Self Loading Concrete Mixer
Engine Brand
-
Engine Model
-
Engine Power
49.5HP
Rated Speed
-
Cooling System
-
Emission Compliance
-
Fuel Tank Capacity
-
Max Travel Speed
22 km/h
Working Speed
-
Gradeability
280 (54%)° / %
Drive Type
-
Service Brake Type
Master cylinder actuated disc brakes
Parking Brake Type
-
Steering Type
-
Steering Modes
-
Turning Radius
-
Drum Output Per Batch
2.3Cu.M
Drum Volume
-
Drum Rotation
0 to 20RPM
Concrete Output Efficiency
-
Loader Bucket Capacity
-
Loading Shovel System
-
Hydraulic Oil Capacity
-
Hydraulic Flow Rate
-
Hydraulic Pressure
-
Wheelbase
-
Operating Weight
-
Laden Weight
6290kg
Tyre Size
-
Tyre Type
-
Water Tank Capacity
380L
Water Pump Capacity
-
Water System Features
-
Battery Voltage
-
Battery Capacity
-
Additional Features
-
Schwing SLM 2600 Self Loading Concrete Mixer
Engine Brand
-
Engine Model
-
Engine Power
74.5HP
Rated Speed
-
Cooling System
-
Emission Compliance
-
Fuel Tank Capacity
-
Max Travel Speed
27km/h
Working Speed
-
Gradeability
24 (44%)° / %
Drive Type
-
Service Brake Type
Master cylinder actuated disc brakes
Parking Brake Type
-
Steering Type
2 stage gear reduction
Steering Modes
Hydrostatic steering
Turning Radius
-
Drum Output Per Batch
2.8Cu.M
Drum Volume
-
Drum Rotation
0 to 20RPM
Concrete Output Efficiency
-
Loader Bucket Capacity
-
Loading Shovel System
415
Hydraulic Oil Capacity
-
Hydraulic Flow Rate
-
Hydraulic Pressure
-
Wheelbase
-
Operating Weight
-
Laden Weight
-
Tyre Size
-
Tyre Type
-
Water Tank Capacity
380L
Water Pump Capacity
-
Water System Features
-
Battery Voltage
-
Battery Capacity
-
Additional Features
-
Conmat CSLM 2800 Self Loading Concrete Mixer
Engine Brand
KOEL
Engine Model
4R1190NA1
Engine Power
74.5HP
Rated Speed
2200RPM
Cooling System
Water Cooled
Emission Compliance
BSIV
Fuel Tank Capacity
100L
Max Travel Speed
0-25km/h
Working Speed
-
Gradeability
20 Deg / 36.4%° / %
Drive Type
Full Time 4 Wheel Drive
Service Brake Type
Hydraulic powered brakes
Parking Brake Type
Hydraulic powered brakes
Steering Type
-
Steering Modes
-
Turning Radius
-
Drum Output Per Batch
2.8Cu.M
Drum Volume
-
Drum Rotation
0-22RPM
Concrete Output Efficiency
-
Loader Bucket Capacity
420 L
Loading Shovel System
-
Hydraulic Oil Capacity
-
Hydraulic Flow Rate
-
Hydraulic Pressure
-
Wheelbase
2350mm
Operating Weight
7100kg
Laden Weight
13820kg
Tyre Size
12.5/80x18
Tyre Type
16 PR
Water Tank Capacity
625L
Water Pump Capacity
230L/min
Water System Features
-
Battery Voltage
-
Battery Capacity
-
Additional Features
-
Apollo Carmix 46 FX Self Loading Concrete Mixer
Engine Brand
Mahindra & Mahindra
Engine Model
MCVNC35TI112CE5
Engine Power
112HP
Rated Speed
2200RPM
Cooling System
-
Emission Compliance
-
Fuel Tank Capacity
130L
Max Travel Speed
26km/h
Working Speed
9km/h
Gradeability
16-18° / %
Drive Type
Electric Servo Control
Service Brake Type
Parking Brake Type
-
Steering Type
Hydraulic. 3 Way
Steering Modes
Reversible seat with automatic inversion of hydraulic steering circuit
Turning Radius
4800mm
Drum Output Per Batch
4.6Cu.M
Drum Volume
6235L
Drum Rotation
-
Concrete Output Efficiency
90-95%
Loader Bucket Capacity
600L
Loading Shovel System
Slewing and hydraulically tilting
Hydraulic Oil Capacity
85L
Hydraulic Flow Rate
-
Hydraulic Pressure
-
Wheelbase
-
Operating Weight
7790kg
Laden Weight
-
Tyre Size
16/70-20 PR 16
Tyre Type
Off Road Type
Water Tank Capacity
1160L
Water Pump Capacity
Self contained Water Pump, Water Meter, Washing Outlet.L/min
Water System Features
-
Battery Voltage
12V
Battery Capacity
180Ah
Additional Features
-
