Volvo L120H Wheel Loader
The Volvo L120H Wheel Loader is engineered for enhanced productivity and cost-efficiency. Featuring advanced technology, including the new OptiShift option and electric servo controls, it offers up to 12% increased productivity and up to 28% improved fuel efficiency compared to previous models. With a static tipping load capacity of 12,500 kg and a powerful breakout force of 170 kN, the L120H excels in handling heavy materials. Its versatile bucket capacity, ranging from 2.6 to 9.5 m³, makes it suitable for various applications, from agriculture to waste and log handling. Powered by the Volvo D8L engine, the L120H combines strength with operational efficiency, making it a reliable choice for demanding tasks with an operating weight of up to 21,600 kg.
Volvo L120H Wheel Loader
The Volvo L120H Wheel Loader is engineered for enhanced productivity and cost-efficiency. Featuring advanced technology, including the new OptiShift option and electric servo controls, it offers up to 12% increased productivity and up to 28% improved fuel efficiency compared to previous models. With a static tipping load capacity of 12,500 kg and a powerful breakout force of 170 kN, the L120H excels in handling heavy materials. Its versatile bucket capacity, ranging from 2.6 to 9.5 m³, makes it suitable for various applications, from agriculture to waste and log handling. Powered by the Volvo D8L engine, the L120H combines strength with operational efficiency, making it a reliable choice for demanding tasks with an operating weight of up to 21,600 kg.
Product Description
The Volvo L120H Wheel Loader is engineered for enhanced productivity and cost-efficiency. Featuring ...
View the full brochure
Volvo L120H Wheel Loader Comparison with Similar Wheel Loader

Volvo L120H Wheel Loader
Engine Brand
Volvo
Engine Model
D8L
Engine Power
190kW
Max Torque
1125Nm
Rated Speed
1700 - 2240rpm
Displacement
7.8L
Fuel Tank Capacity
270L
Hydraulic Oil Capacity
140L
Transmission Type
Volvo HTE 206F APS
Number Of Gears (f/r)
4/4
Max Travel Speed (f)
40km/h
Max Travel Speed (r)
40km/h
Service Brake Type
Wet disc, dual circuit with accumulators
Parking Brake Type
Wet multi-disc, spring applied, electro-hydraulic release
Steering Type
Hydrostatic articulated, load-sensing
Steering Angle
40°
Oscillation Angle
13°
Turning Radius
-
Operating Weight
20.21kg
Front Axle Load
-
Rear Axle Load
-
Max Lifting Capacity
-
Hydraulic Flow Rate
128L/min
Hydraulic Pressure
290Bar
Overall Length
8.93m
Overall Width
2.99m
Overall Height
3.33m
Ground Clearance
435mm
Max Dump Height
2.84m
Max Load Over Height
4.66m
Max Reach At Full Height
-
Loader Bucket Capacity
3.8m³
Loader Arm Breakout Force
163.7kN
Front Axle Oscillation
13°
Battery Voltage
24V
Standard Tires (front/rear)
23.5 R25 L3
Emission Standard
-
Max Travel Speed
-
Rated Operating Capacity
-
Rated Operating Capacity (optional)
-
Max Tipping Load
-
Hydraulic System Capacity
-
Max Hinge Pin Height
-
Reach At Ground Level
-
Bucket Capacity
-
Dump Angle
-
Lift Path
-
Wheelbase
-

Volvo L350H Wheel Loader
Engine Brand
Volvo
Engine Model
D16E
Engine Power
397kW
Max Torque
2550Nm
Rated Speed
1700–1800rpm
Displacement
16.1L
Fuel Tank Capacity
540L
Hydraulic Oil Capacity
365L
Transmission Type
Volvo HTL 500, APS, ECM controlled
Number Of Gears (f/r)
4/4
Max Travel Speed (f)
37.7km/h
Max Travel Speed (r)
37.7km/h
Service Brake Type
Dual circuit, oil-cooled, wet disc brakes
Parking Brake Type
Dry, spring-applied, electro-hydraulically released
Steering Type
Load-sensing hydrostatic articulated steering
Steering Angle
±37°
Oscillation Angle
±12°
Turning Radius
-
Operating Weight
-
Front Axle Load
-
Rear Axle Load
-
Max Lifting Capacity
-
Hydraulic Flow Rate
827L/min
Hydraulic Pressure
29Bar
Overall Length
-
Overall Width
-
Overall Height
-
Ground Clearance
550mm
Max Dump Height
-
Max Load Over Height
-
Max Reach At Full Height
-
Loader Bucket Capacity
-
Loader Arm Breakout Force
-
Front Axle Oscillation
±12°
Battery Voltage
24V
Standard Tires (front/rear)
35/65 R33 L4
Emission Standard
-
Max Travel Speed
-
Rated Operating Capacity
-
Rated Operating Capacity (optional)
-
Max Tipping Load
-
Hydraulic System Capacity
-
Max Hinge Pin Height
-
Reach At Ground Level
-
Bucket Capacity
-
Dump Angle
-
Lift Path
-
Wheelbase
-

Volvo L260H Wheel Loader
Engine Brand
Volvo
Engine Model
D13E
Engine Power
310kW
Max Torque
2343Nm
Rated Speed
1400–1900rpm
Displacement
12.8L
Fuel Tank Capacity
366L
Hydraulic Oil Capacity
226L
Transmission Type
Volvo Automatic Power Shift (APS), 4-speed
Number Of Gears (f/r)
4/4
Max Travel Speed (f)
36.5km/h
Max Travel Speed (r)
36.1km/h
Service Brake Type
Wet disc, oil-cooled, outboard-mounted
Parking Brake Type
Dry disc, electro-hydraulic
Steering Type
Load-sensing hydrostatic articulated
Steering Angle
37°
Oscillation Angle
15°
Turning Radius
-
Operating Weight
33.76kg
Front Axle Load
-
Rear Axle Load
-
Max Lifting Capacity
-
Hydraulic Flow Rate
252L/min
Hydraulic Pressure
290Bar
Overall Length
9.31m
Overall Width
3.58m
Overall Height
6.46m
Ground Clearance
600mm
Max Dump Height
3.33m
Max Load Over Height
6.46m
Max Reach At Full Height
2.28m
Loader Bucket Capacity
6.1m³
Loader Arm Breakout Force
311kN
Front Axle Oscillation
15°
Battery Voltage
24V
Standard Tires (front/rear)
29.5 R25 L4
Emission Standard
-
Max Travel Speed
-
Rated Operating Capacity
-
Rated Operating Capacity (optional)
-
Max Tipping Load
-
Hydraulic System Capacity
-
Max Hinge Pin Height
-
Reach At Ground Level
-
Bucket Capacity
-
Dump Angle
-
Lift Path
-
Wheelbase
-

ACE SS 75 Skid Steer Loader
Engine Brand
ACE / Simpson
Engine Model
A50 / TSJ436
Engine Power
50 / 60 / 75HP
Max Torque
-
Rated Speed
2100 / 2200rpm
Displacement
-
Fuel Tank Capacity
55L
Hydraulic Oil Capacity
-
Transmission Type
Infinitely variable hydrostatic drive
Number Of Gears (f/r)
-
Max Travel Speed (f)
-
Max Travel Speed (r)
-
Service Brake Type
-
Parking Brake Type
-
Steering Type
-
Steering Angle
-
Oscillation Angle
-
Turning Radius
-
Operating Weight
2.85Ton
Front Axle Load
-
Rear Axle Load
-
Max Lifting Capacity
-
Hydraulic Flow Rate
82L/min
Hydraulic Pressure
-
Overall Length
3.62m
Overall Width
1.645m
Overall Height
2.11m
Ground Clearance
185mm
Max Dump Height
2.29m
Max Load Over Height
-
Max Reach At Full Height
0.68m
Loader Bucket Capacity
-
Loader Arm Breakout Force
-
Front Axle Oscillation
-
Battery Voltage
-
Standard Tires (front/rear)
-
Emission Standard
Bharat (TREM) Stage III A / CEV / BSIII / Tier 2 / BS-III
Max Travel Speed
10km/h
Rated Operating Capacity
750kg
Rated Operating Capacity (optional)
-
Max Tipping Load
1500kg
Hydraulic System Capacity
65L
Max Hinge Pin Height
3.15m
Reach At Ground Level
-
Bucket Capacity
0.4m³
Dump Angle
40°
Lift Path
-
Wheelbase
1.01m

Volvo L150H Wheel Loader
Engine Brand
Volvo
Engine Model
D13F
Engine Power
300kW
Max Torque
1999Nm
Rated Speed
1300rpm
Displacement
12.8L
Fuel Tank Capacity
366L
Hydraulic Oil Capacity
156L
Transmission Type
Volvo HTL 223
Number Of Gears (f/r)
-
Max Travel Speed (f)
38km/h
Max Travel Speed (r)
-
Service Brake Type
Wet Disc
Parking Brake Type
Dry Disc
Steering Type
Articulated
Steering Angle
37°
Oscillation Angle
15°
Turning Radius
-
Operating Weight
26.47kg
Front Axle Load
-
Rear Axle Load
-
Max Lifting Capacity
7700kg
Hydraulic Flow Rate
180L/min
Hydraulic Pressure
290Bar
Overall Length
8.58m
Overall Width
2.93m
Overall Height
3.51m
Ground Clearance
0.61mm
Max Dump Height
3.15m
Max Load Over Height
-
Max Reach At Full Height
-
Loader Bucket Capacity
4.0m³
Loader Arm Breakout Force
201.2kN
Front Axle Oscillation
15°
Battery Voltage
24V
Standard Tires (front/rear)
26.5 R25 L3
Emission Standard
-
Max Travel Speed
-
Rated Operating Capacity
-
Rated Operating Capacity (optional)
-
Max Tipping Load
-
Hydraulic System Capacity
-
Max Hinge Pin Height
-
Reach At Ground Level
-
Bucket Capacity
-
Dump Angle
-
Lift Path
-
Wheelbase
-
